Parker Polyflex 2020N系列高压软管

RonWang4年前 (2020-04-06)工业技术467

Parker Polyfelx Pressure Diagnostic Hose 2020N 0-63Mpa

2020N  Hydraulic Hose (high pressrure) -Small bore hose

Main Features:    Small dimesions / Small bend radii / Working pressure up to 63Mpa

Application: Versatile usage in mini-hydraulic and gas application

Construction:

Core tube : Polyamide

Pressure reinforcement : One braided layer of   high tensile syntheic fibre

Cover : Polyamide,pinpricked  Colour :   black

Tempeature Range: -40℃ up to +100℃ for petroleum or synthetic hydraulic fluids.

Part No.SIZEMax W.P.Min B. P.Min Bend
#mmmmMpapsiMpapsimm
2020N-012V302.04.95072502002900020
2020N-016V302.55.94058001602320020
2020N-02V302.96.04058001602320030
2020N-025V304.08.14463801762552040
2020N-012V302.04.96391352002900020

Notes: V50:Design factor reduced for diagnostic applications.
2020N-02V30 and 2020N-025V30 With DNV approval for hydraulics systems

Polyflex 2020N
